Cold Drawn Electroplated Surface High Strength Transformer Copper Foil Beryllium Bronze C17200
  • name
  • name
  • name
  • name
  • name
  • name

Cold Drawn Electroplated Surface High Strength Transformer Copper Foil Beryllium Bronze C17200

MOQ: 1
prezzo: 1
Informazione dettagliata
Descrizione di prodotto
Informazione dettagliata
Certificazione
ISO9001, ASTM, JIS, GB, EN
documento
Brochure del prodotto PDF
Modello n.:
C17200
Tecnica:
Cold Drawn
Grado:
Serie 1000
Lega:
Lega
Trattamento superficiale:
Cloruro di potassio
capacità produttiva:
5000 mt/mese
Sii contenuto:
1,8-2,0%
Contenuto Ni+Co:
>=0,2%
Contenuto Ni+Co+Fe:
<=0,6%
Contenuto di Cu+Be+Ni+Co+Fe:
>=99,5%
Conduttività:
>=25% IACS
Intervallo di resistenza alla trazione:
390-1520 N/m2
Gamma di allungamento:
1-65%
Gamma di durezza:
90-450 hv
Pacchetto di trasporto:
Pacchetto standard di esportazione per il trasporto marittimo
Quantità di ordine minimo:
1
Prezzo:
1
Evidenziare:

Cold Drawn Transformer Copper Foil

,

Electroplated Surface Beryllium Bronze Foil

,

High Strength C17200 Copper Foil

Descrizione di prodotto
 PRODUCT SHOW

Cold Drawn Electroplated Surface High Strength Transformer Copper Foil Beryllium Bronze C17200 0


CHEMICAL COMPOSITION

Alloy Chemical Composition(%)
ASTM JIS GB Be Ni+Co Ni+Co+Fe Cu+Be+Ni+Co+Fe
C17200 C1720 QBe2.0 1.8-2.0 >=0.2 <=0.6 >=99.5
Features and Use Excellent physical and chemical properties, high strength and elasticity, fatigue resistance, electrical and thermal conductivtity, corrosion resistance good wear resistance, not magnetic characteristics and no spark in the mold manufacturing. In the industries of indutries of mold manufacture, machinery, electronics and other business are widely used.

PHYSICS PROPERTIES

ASTM Temper GB Conductivity(IACS) Tensile Strength(N/m2) Elongation(%) Hardness(hv)
C17200 TB00(A) QBe2.0 >=25% 390-590 35-65 90-144
TD01(1/4H) QBe2.0 >=25% 510--630 10-45 120-220
TD02(1/2H) QBe2.0 >=25% 570-695 5-30 140-240
TD04(H) QBe2.0 >=25% 635-930 2-18 170-287
TF00(AT) QBe2.0 >=25% 1080-1470 2-15 320-413
TH01(1/4HT) QBe2.0 >=25% 1135--1420 2-10 320-430
TH02(1/2HT) QBe2.0 >=25% 1145-1490 1-8 340-440
TH04(H) QBe2.0 >=25% 1310-1520 1-6 360-450
TM0O(AM) QBe2.0 >=25% 690-760 >=16 210-251
TM01(1/4HM) QBe2.0 >=25% 760--830 >=15 230-271
TM02(1/2HM) QBe2.0 >=25% 830-930 >=12 250-339
TM04(HM) QBe2.0 >=25% 930-1030 >=9 285-343
TH06(XHM) QBe2.0 >=25% 1030--1100 >=9 309-369
TH08(XHMS) QBe2.0 >=25% 1070--1210 >=4 317-393

Remarks:confirmed, can provide surface electroplating, reflow plating, hot-dip plating materials.

Company advantage

Cold Drawn Electroplated Surface High Strength Transformer Copper Foil Beryllium Bronze C17200 1

Quality is guaranteed. Since its establishment, JIACHEN is committed to providing high quality products and efficient service and has been adhering to the road of high-tech development.
Technology equipment is advanced. Our partners have high-precision, high-efficiency modern professional production equipment: import slitting machine(1600mm), precision slitting machine (450mm), precision slitting machine(650mm), imports of horizontal shears(flying shear 850mm) Shears(shear cut 650mm), the overall production equipment in the same industry-leading level.
Cold Drawn Electroplated Surface High Strength Transformer Copper Foil Beryllium Bronze C17200 2Cold Drawn Electroplated Surface High Strength Transformer Copper Foil Beryllium Bronze C17200 3
Service is trustworthy. We have been a high-quality supplier of made-in-china network, has been committed to foreign trade, foreign trade capacity has been audited by made-in-china network. We sincerely and warmly welcome you to visit and give advice to improve our shortcomings, learn new technologies, improve product performance, and mutual benefit.
